MOBILE PROCESSING PLANTS

SPEEDMINER® FULLY MOBILE PLANTS

DOVE is the exclusive and premier manufacturer of the largest range of Mobile Plants. SPEEDMINER® Mobile Processing Plants are exclusively designed, developed and patented by DOVE Equipment & Machinery Co., Ltd. and supplied in variuos configurations for Alluvial and Hard Rock mining operations.

  • SPEEDMINER® mobile plants are designed for rapid deployment in the mining area. SPEEDMINER® mobile processing plants are shipped in 40 Feet containers and are configured for rapid assembly in mining site, and designed for ease of logistics and movement in the mining site. No site construction.
  • SPEEDMINER® mobile plants are produced in various configuration and are tailor made to adopt to specification of each project, in accordance to the ore characteristic, minerals composition, mine location, project size, etc. We supply mobile plants for Hard Rock and Alluvial deposits.
  • SPEEDMINER® mobile plants produced in 18 Models, for both Alluvial and Hard Rock mining operations, with total capacity range of 5 – 120 Tons/Hour (20 – 480 m3/Hour), are configured as a complete self-sufficient plant, designed for continuous recovery of gold, diamonds, gemstones, and other Metals & Minerals, to the micron size.
  • SPEEDMINER® mobile plants are produced in 3 models, capacity range of 5-20 Tons/Hour for application of Hard rock (Primary) deposits, and 15 models, capacity range of 5-120 Tons/Hour solids for application of Alluvial (Placer) gold, diamonds and other metals.
  • SPEEDMINER® mobile plant are designed with security system and locking mechanism, to prevent the unauthorized access and the theft of the production.
  • SPEEDMINER® mobile plant is highly efficient and economical, designed for highest recovery ratio of metals and minerals, as well as environment friendly, as they only require recycled water. They do not require clean water or any chemicals.
  • SPEEDMINER® is designed for rapid assembly at your mine site and there are no site construction is required. SPEEDMINER®mobile plants are an economical and suitable option for rapid operation start-ups.
  • SPEEDMINER® plants are designed and configured for automatic and simultaneous classification, concentration and recovery of Gold, Diamond, Gemstones, other Metals and Minerals with highest recovery and down to micron size.

TECHNICAL SPECIFICATIONS

SPEEDMINER® MODELS PRODUCT DESCRIPTION PROCESSING CAPACITY
SOLIDS / HOUR SLURRY / HOUR
TONS CUBIC METERS CUBIC YARDS CUBIC METERS CUBIC YARDS
SPA – 5G ALLUVIAL GOLD MOBILE PROCESSING PLANT 5-8 3.3.-5.3 4.1-6.6 20-32 26.2-41.9
SPA – 5D ALLUVIAL DIAMOND MOBILE PROCESSING PLANT 5-8 3.3.-5.3 4.1-6.6 20-32 26.2-41.9
SPA – 5GD ALLUVIAL GOLD & DIAMOND MOBILE PROCESSING PLANT 5-8 3.3.-5.3 4.1-6.6 20-32 26.2-41.9
SPA – 10G ALLUVIAL GOLD MOBILE PROCESSING PLANT 10-15 6.7-10 8.2-12.3 40-60 52.3-78.5
SPA – 10D ALLUVIAL DIAMOND MOBILE PROCESSING PLANT 10-15 6.7-10 8.2-12.3 40-60 52.3-78.5
SPA – 10GD ALLUVIAL GOLD & DIAMOND MOBILE PROCESSING PLANT 10-15 6.7-10 8.2-12.3 40-60 52.3-78.5
SPA – 20G ALLUVIAL GOLD MOBILE PROCESSING PLANT 20-25 13.3-16.7 16.5-20.6 80-100 104.6-130.8
SPA – 20D ALLUVIAL DIAMOND MOBILE PROCESSING PLANT 20-25 13.3-16.7 16.5-20.6 80-100 104.6-130.8
SPA – 20GD ALLUVIAL GOLD & DIAMOND MOBILE PROCESSING PLANT 20-25 13.3-16.7 16.5-20.6 80-100 104.6-130.8
SPA – 50G ALLUVIAL GOLD MOBILE PROCESSING PLANT 50-60 33.3-40 41.2-49.4 200-240 261.6-313.9
SPA – 50D ALLUVIAL DIAMOND MOBILE PROCESSING PLANT 50-60 33.3-40 41.2-49.4 200-240 261.6-313.9
SPA – 50GD ALLUVIAL GOLD & DIAMOND MOBILE PROCESSING PLANT 50-60 33.3-40 41.2-49.4 200-240 261.6-313.9
SPA -100G ALLUVIAL GOLD MOBILE PROCESSING PLANT 100-120 66.7-80 82.3-98.8 400-480 523.2-627.8
SPA -100D ALLUVIAL DIAMOND MOBILE PROCESSING PLANT 100-120 66.7-80 82.3-98.8 400-480 523.2-627.8
SPA – 100GD ALLUVIAL GOLD & DIAMOND MOBILE PROCESSING PLANT 100-120 66.7-80 82.3-98.8 400-480 523.2-627.8
SPH – 5G HARD ROCK MOBILE PROCESSING PLANT 5-8 3.3.-5.3 4.1-6.6  –  –
SPH – 10G HARD ROCK MOBILE PROCESSING PLANT 10-12 6.7-8 8.2-9.9  –  –
SPH – 15G HARD ROCK MOBILE PROCESSING PLANT 15-20 10-13.3 12.3-16.5  –  –

* DOVE reserves the right to modify the specifications at anytime, without prior notice.

Please, Contact Us for more information about SPEEDMINER® plants: info@dovemining.com.

DOVE laboratory will assay your ore samples rapidly and analyze your raw materials and recommend the most efficient processing plant according to the ore specifications, minerals composition, and ore assay results, and your project size and the geologic and topographic conditions of your mine.
Please, contact us for your sample analysis and quotation: info@dovemining.com.
Mineral testing laboratory room, DOVE laboratory in Bangkok
All DOVE equipment carry a 2 years (24 months) standard Manufacturer Warranty, which can be extended to 5 years, in addition to lifetime spare parts service supply.
DOVE provides full technical services worldwide, including plant engineering design, mining site construction design, site assembly, installation, test run and training.

We highly recommend forwarding soil samples of your mine to us for analysis, in order to design and recommend the most efficient processing plant, tailor made to your mine requirements, for highest production recovery.

Contact us for Brochure & Quotation!

DOVE Sales Department will help find the best solutions for your mining project.
