EXPLORER® PORTABLE WASH PLANTS
Potable Wash Plants, also known as Portable Gold Wash Plants, Portable Diamond Wash Plants, Small Gold Wash Plant, Portable Gold Mining Equipment, Portable Gold Mining Wash Plants, Small Gold Mining Equipment, or Portable Gold Trommel Wash Plants
DOVE PORTABLE WASH PLANTS APPLICATION
The EXPLORER® Portable Processing Plants are Portable Wash Plants exclusively designed, patented and developed by DOVE, for surface mining of alluvial (placer) Gold, Diamonds, color Gemstones, Base metals and Ferrous metals.
VARIOUS CONFIGURATIONS BASED ON YOUR REQUIREMENTS:
EXPLORER® Portable Alluvial Processing Plants (Portable Wash Plants) are produced in 47 models, with capacity ranging from 2-1,000 TPH (metric tons per hour) solids (20-10,000 metric tons per day) single shift of operation.
DOVE PORTABLE PLANTS FEATURES
Efficiency
EXPLORER® Portable Plants are configured and customized with multy-stage classifier and concentrators according to the ore specification as a fully integrated processing plant for 100% recovery of gold, diamonds, base metals, ferrous metals, with no loss.
SIMULTANEOUS PROCESSING
Fully integrated EXPLORER® Portable Plants are designed for automatic and simultaneous processing and recovery of gold, diamonds and precious stones together.
PRODUCTION SECURITY
EXPLORER® Portable Plants are configured with full security system and locking mechanism, to protect the (gold, diamond, precious stones) production from the unauthorized access.
PORTABILITY
EXPLORER® Portable Plants are easily assembled, disassembled, installed and transported through the mining site, resulting in rapid deployment on the site. Plants are fully portable to allow ease of movement in the field.
USER-FRIENDLY
EXPLORER® Portable Plants offer features such as the ability to easily be operated and maintained on the site, and don’t require much human interference during the processing of the minerals, offering a user-friendly experience.
ENVIRONMENT-FRIENDLY
No environmental impact, chemical free, requires only recycled water.
CUSTOMIZED SOLUTION FOR MINING OPERATIONS:
EXPLORER® Portable Plants can be tailor made according to the mine specifications and customized to be integrated with various portable equipment in order to form a complete production line for the full recovery of minerals.
EXPLORER® PORTABLE GOLD PROCESSING PLANTS
(PORTABLE GOLD WASH PLANTS)
EXPLORER® Portable Gold Processing Plants are designed for recovery of alluvial Gold and are configured with our specialized Multi-Stage Classifier designed with Scrubber and Clay breaker mechanism. Plant configuration enables the separation of fines from mid-size material and oversize rejects at early stage, to eliminate any chance for loss of fine gold, while simultaneously resolving and processing the heavy clay content as well. In combination with our Duplex Jig Concentrators, DOVE Centrifugal Concentrators, or VBS® Concentrators, EXPLORER® plants ensure the capture of both gold nuggets over 2 mm, and fine Gold below 2 mm all the way down to 40 microns (0.040mm), with absolutely no loss and 100% recovery.
TECHNICAL SPECIFICATIONS
| EXPLORER® PORTABLE PLANT MODELS | PRODUCT DESCRIPTION | CAPACITY | |||||
|---|---|---|---|---|---|---|---|
| SOLIDS / HOUR | SLURRY / HOUR | ||||||
| METRIC TONS | CUBIC METERS | CUBIC YARDS | CUBIC METERS | CUBIC YARDS | |||
| EXP – 15G | PORTABLE GOLD PROCESSING PLANT | 10-15 | 7-10 | 8-12 | 40-60 | 52-78 | |
| EXP – 25G | PORTABLE GOLD PROCESSING PLANT | 20-25 | 13-17 | 16-21 | 80-100 | 105-131 | |
| EXP – 35G | PORTABLE GOLD PROCESSING PLANT | 25-35 | 17-23 | 21-29 | 100-140 | 131-183 | |
| EXP – 45G | PORTABLE GOLD PROCESSING PLANT | 35-45 | 23-30 | 29-37 | 140-180 | 183-235 | |
| EXP – 60G | PORTABLE GOLD PROCESSING PLANT | 50-60 | 33-40 | 41-49 | 200-240 | 262-314 | |
| EXP – 90G | PORTABLE GOLD PROCESSING PLANT | 80-90 | 53-60 | 66-74 | 320-360 | 419-471 | |
| EXP – 120G | PORTABLE GOLD PROCESSING PLANT | 100-120 | 67-80 | 82-99 | 400-480 | 523-628 | |
| EXP – 170G | PORTABLE GOLD PROCESSING PLANT | 150-170 | 100-113 | 123-140 | 600-680 | 785-889 | |
| EXP – 220G | PORTABLE GOLD PROCESSING PLANT | 200-220 | 133-147 | 165-181 | 800-880 | 1,046-1,151 | |
EXPLORER® Plants for Gold are produced in 15 models,
capacity range of 10-820 TPH (100-8,200 TPD) single shift.
EXPLORER® PORTABLE DIAMOND PROCESSING PLANTS
(PORTABLE DIAMOND WASH PLANTS)
EXPLORER® Portable Diamond Processing Plants are designed for recovery of alluvial Diamonds and color Gemstones. The plants are configured with our Trommels Classifier Screens / Scrubber Screens, which enables the plant to thoroughly wash the ore and break the hosting clay. Together, with the addition of our Duplex Primary and Secondary Jig Concentrators, or Scavenger Jig Modules, it becomes possible to simultaneously process, concentrate, and separate coarse and fine Diamonds down to 2 mm, with 100% recovery and absolutely no loss. In cases of requirements to recover Diamonds below 2mm, plants can be configured with the supplementing of VBS® Concentrator.
| EXPLORER® PORTABLE PLANT MODELS | PRODUCT DESCRIPTION | CAPACITY | |||||
|---|---|---|---|---|---|---|---|
| SOLIDS / HOUR | SLURRY / HOUR | ||||||
| METRIC TONS | CUBIC METERS | CUBIC YARDS | CUBIC METERS | CUBIC YARDS | |||
| EXP – 3D | PORTABLE DIAMOND PROCESSING PLANT | 2-3 | 1-2 | 2 | 8-12 | 10-16 | |
| EXP – 8D | PORTABLE DIAMOND PROCESSING PLANT | 5-8 | 3-5 | 4-7 | 20-32 | 26-42 | |
| EXP – 15D | PORTABLE DIAMOND PROCESSING PLANT | 10-15 | 7-10 | 8-12 | 40-60 | 52-78 | |
| EXP – 25D | PORTABLE DIAMOND PROCESSING PLANT | 20-25 | 13-17 | 16-21 | 80-100 | 105-131 | |
| EXP – 30D | PORTABLE DIAMOND PROCESSING PLANT | 25-30 | 17-20 | 21-25 | 100-120 | 131-157 | |
| EXP – 50D | PORTABLE DIAMOND PROCESSING PLANT | 40-50 | 27-33 | 33-41 | 160-200 | 209-262 | |
| EXP – 90D | PORTABLE DIAMOND PROCESSING PLANT | 80-90 | 53-60 | 66-74 | 320-360 | 419-471 | |
| EXP – 120D | PORTABLE DIAMOND PROCESSING PLANT | 100-120 | 67-80 | 82-99 | 400-480 | 523-628 | |
| EXP – 170D | PORTABLE DIAMOND PROCESSING PLANT | 150-170 | 100-113 | 123-140 | 600-680 | 785-889 | |
| EXP – 220D | PORTABLE DIAMOND PROCESSING PLANT | 200-220 | 133-147 | 165-181 | 800-880 | 1,046-1,151 | |
EXPLORER® Plants for Diamonds are produced in 17 models,
capacity range of 2-1,000 TPH (20-10,000 TPD) single shift.
EXPLORER® PORTABLE GOLD AND DIAMOND PROCESSING PLANTS (PORTABLE GOLD AND DIAMOND WASH PLANTS)
EXPLORER® Portable Gold and Diamond Processing Plants are exclusively designed for recovery of Gold and Diamonds simultaneously. Plants are configured with specialized DOVE Multi-Stage Classifier designed with Scrubber and Clay breaker mechanism, enabling the separation of fines from mid-size material and oversize rejects at early stage, to eliminate any chance for loss of fine Gold & Diamonds, simultaneously as well as resolving the heavy clay content and liberating the gold and diamonds from the host clay. Duplex Primary and Secondary Jig Concentrators and Scavenger Jig Modules for the recovery of gold nuggets and coarse diamonds over 2 mm, and DOVE Centrifugal Gold Concentrators or alternatively VBS® Concentrators for the recovery of fine Gold and Diamond particles below 2 mm. The plants are designed to achieve 100% recovery of Gold and Diamond particles simultaneously, all the way down to 40 microns (0.040 mm), with no loss.
| EXPLORER® PORTABLE PLANT MODELS | PRODUCT DESCRIPTION | CAPACITY | |||||
|---|---|---|---|---|---|---|---|
| SOLIDS / HOUR | SLURRY / HOUR | ||||||
| METRIC TONS | CUBIC METERS | CUBIC YARDS | CUBIC METERS | CUBIC YARDS | |||
| EXP – 15GD | PORTABLE GOLD & DIAMOND PROCESSING PLANT | 10-15 | 7-10 | 8-12 | 40-60 | 52-78 | |
| EXP – 25GD | PORTABLE GOLD & DIAMOND PROCESSING PLANT | 20-25 | 13-17 | 16-21 | 80-100 | 105-131 | |
| EXP – 35GD | PORTABLE GOLD & DIAMOND PROCESSING PLANT | 25-35 | 17-23 | 21-29 | 100-140 | 131-183 | |
| EXP – 45GD | PORTABLE GOLD & DIAMOND PROCESSING PLANT | 35-45 | 23-30 | 29-37 | 140-180 | 183-235 | |
| EXP – 60GD | PORTABLE GOLD & DIAMOND PROCESSING PLANT | 50-60 | 33-40 | 41-49 | 200-240 | 262-314 | |
| EXP – 90GD | PORTABLE GOLD & DIAMOND PROCESSING PLANT | 80-90 | 53-60 | 66-74 | 320-360 | 419-471 | |
| EXP -120GD | PORTABLE GOLD & DIAMOND PROCESSING PLANT | 100-120 | 67-80 | 82-99 | 400-480 | 523-628 | |
| EXP – 170 GD | PORTABLE GOLD & DIAMOND PROCESSING PLANT | 150-170 | 100-113 | 123-140 | 600-680 | 785-889 | |
| EXP -220 GD | PORTABLE GOLD & DIAMOND PROCESSING PLANT | 200-220 | 133-147 | 165-181 | 800-880 | 1,046-1,151 | |
EXPLORER® Plants for Gold and Diamonds are produced in 15 models,
capacity range of 10-820 TPH (100-8,200 TPD) single shift.
* DOVE reserves the right to modify the specifications at anytime, without prior notice.
WARRANTY:
All DOVE equipment carry a standard Manufacturer’s Warranty, which can be extended to 5 years, in addition to lifetime spare parts supply service.
DOVE provides full technical services worldwide, including plant engineering design, mining site construction design, site assembly, installation, test run and training.
MANUFACTURING FACILITIES:
DOVE Equipment & Machinery manufacturing facilities are located about 30 minutes drive from the company Head office in Bangkok, which includes 8 factories and showroom.
DOVE Equipment and Machinery with over 50 years manufacturing expertise, and the largest range of mining and minerals processing technologies is the recipient of ISO 9001: 2015, Green Industry Certification, and Golden Eagle of Asia Awards 2020 Best Business of the Year (DOVE Equipment and Machinery and DOVE Instruments), which insures highest quality and standard of our manufacturing and customer service practices.
DOVE Manufacturing Facilities.
DOVE Equipment and Machinery 8 Factories.
Video DOVE Manufacturing Facilities:
MINERAL TEST SERVICES:
DOVE laboratory will assay your ore samples rapidly and analyze your raw materials and recommend the most efficient processing plant according to the ore specifications, minerals composition, and ore assay results, and your project size and the geologic and topographic conditions of your mine.
Please, CONTACT US for your sample analysis and quotation.
WE HIGHLY RECOMMEND FORWARDING SOIL SAMPLES OF YOUR MINE TO US FOR ANALYSIS, IN ORDER TO DESIGN AND RECOMMEND THE MOST EFFICIENT PROCESSING PLANT, TAILOR MAID TO YOUR MINE REQUIREMENTS, FOR HIGHEST PRODUCTION RECOVERY.
